TENGEN TGX01-75kW 200V 60Hz Cu Primary Busbar Autotransformer Starter
- Brand
- TENGEN
- Model
- TGX01-75kW 200V 60Hz Cu Primary Busbar
- GEARWELL SKU
- GWP-000021354
- Category
- Contactors & Starters
Key specifications
- Series
- TGX01 autotransformer reduced-voltage starter cabinet
- Version
- primary circuit with copper busbar
- Material number
- 341010100027
- Rated motor power
- 75 kW
- Autotransformer taps
- 65% (60%) and 80%; supplied on 80%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TENGEN TGX01-75kW 200V 60Hz Cu Primary Busbar Autotransformer Starter |
|---|---|
| Brand | TENGEN |
| Model | TGX01-75kW 200V 60Hz Cu Primary Busbar |
| Category | Contactors & Starters |
| Series | TGX01 autotransformer reduced-voltage starter cabinet |
| Version | primary circuit with copper busbar |
| Material number | 341010100027 |
| Rated motor power | 75 kW |
| Autotransformer taps | 65% (60%) and 80%; supplied on 80% |
| Official designation | TGX01-75kW 200V 60Hz (primary circuit copper busbar), listed in the TENGEN zx selection SKU list of product 11713 |
| Start time per start | <= 15 s (light-load, infrequent starting) |
| Rated voltage / frequency (as collected) | 200 V 60 Hz |
