TENGEN TGX01-40KW Cu Autotransformer Starter Cabinet

Key specifications

Series: TGX01 autotransformer reduced-voltage starter cabinet
Variant: copper-wound autotransformer (official SKU name 'TGX01-40KW 铜', remark 变压器铜线)
Rated voltage: 380 V
Material number: 04080010056
Rated motor power: 40 kW

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	TENGEN TGX01-40KW Cu Autotransformer Starter Cabinet
Brand	TENGEN
Model	TGX01-40KW Cu
Category	Contactors & Starters
Series	TGX01 autotransformer reduced-voltage starter cabinet
Variant	copper-wound autotransformer (official SKU name 'TGX01-40KW 铜', remark 变压器铜线)
Rated voltage	380 V
Material number	04080010056
Rated motor power	40 kW
Autotransformer taps	65% (60%) and 80%; supplied on 80%
Start time per start	<= 15 s (light-load, infrequent starting)
Output (start tap) voltage	380 / 304 (80% tap) V
Current transformer ratio	200/5
Max operating current at 380 V	80 A
