ABB EK110-40-11 EK contactors 4-pole contactor (220-230V 50Hz, SK824440-AL)
- Brand
- ABB
- Model
- EK110-40-11
- GEARWELL SKU
- GWP-000029231
- Category
- Contactors & Starters
Key specifications
- Main poles
- 4
- Coil voltage
- 220-230 V 50 Hz
- Auxiliary contacts
- 1 NO + 1 NC
- Conductor cross-section
- 95 mm²
- Rated operational voltage
- 1000 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB EK110-40-11 EK contactors 4-pole contactor (220-230V 50Hz, SK824440-AL) |
|---|---|
| Brand | ABB |
| Model | EK110-40-11 |
| Category | Contactors & Starters |
| Main poles | 4 |
| Coil voltage | 220-230 V 50 Hz |
| Auxiliary contacts | 1 NO + 1 NC |
| Conductor cross-section | 95 mm² |
| Rated operational voltage | 1000 V |
| AC-1 rated operational current (θ < 40 °C) | 200 A |
| AC-1 rated operational current (θ < 55 °C) | 180 A |
| AC-1 rated operational current (θ < 70 °C) | 155 A |
