Supmea WZPK-PA00L206500M1M150WF WZPK RTD Sensor
- Brand
- Supmea
- Model
- WZPK-PA00L206500M1M150WF
- GEARWELL SKU
- GWP-000022334
- Category
- Pressure, Flow & Temperature
Key specifications
- RTD type
- Pt100, class A (PA)
- Materials
- 304SS process connection and probe (M1/M1)
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Probe type
- Insertion depth without thread (0)
- Sheath length
- 50 (50) mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea WZPK-PA00L206500M1M150WF WZPK RTD Sensor |
|---|---|
| Brand | Supmea |
| Model | WZPK-PA00L206500M1M150WF |
| Category | Pressure, Flow & Temperature |
| RTD type | Pt100, class A (PA) |
| Materials | 304SS process connection and probe (M1/M1) |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Probe type | Insertion depth without thread (0) |
| Sheath length | 50 (50) mm |
| Terminal head | M20x1.5 cable gland, aluminium alloy, IP65 (WF) |
| Cold end length | 50 (50) mm |
| Sheath diameter | 6 (06) mm |
| Process connection | M20x1.5 thread (L2) |
| Transmitter output | None (00) |
| Ordering code (decoded) | SUP-WZPK-PA-00-L2-06-50-0-M1-M1-50-WF |
