Supmea FSC400-W3T7LADWY05XX Wall-Mounted Ultrasonic Flowmeter
- Brand
- Supmea
- Model
- FSC400-W3T7LADWY05XX
- GEARWELL SKU
- GWP-000022307
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy (L)
- Class 1.0
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Housing (WY)
- M20x1.5 cable gland, ABS, IP65
- Maker note
- Meacon (Hangzhou Meikong); series and model key published on the Supmea official site
- Transducer (W3)
- Medium clamp-on, DN50-DN700
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea FSC400-W3T7LADWY05XX Wall-Mounted Ultrasonic Flowmeter |
|---|---|
| Brand | Supmea |
| Model | FSC400-W3T7LADWY05XX |
| Category | Pressure, Flow & Temperature |
| Accuracy (L) | Class 1.0 |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Housing (WY) | M20x1.5 cable gland, ABS, IP65 |
| Maker note | Meacon (Hangzhou Meikong); series and model key published on the Supmea official site |
| Transducer (W3) | Medium clamp-on, DN50-DN700 |
| Code suffix "XX" | as collected; not listed in the official model-number table |
| Cable length (05) | 5 m |
| Output and power (AD) | Pulse + 4-20 mA + RS485 + SPST, 24 VDC/220 VAC dual supply |
| Temperature rating (T7) | -30 to 90 °C |
| Sensor material options | NS ABS (standard) / M1 304SS (specify on order) |
