SMC VQC2400BN-51 Solenoid Valve
- Brand
- SMC
- Model
- VQC2400BN-51
- GEARWELL SKU
- GWP-000004352
- Category
- Industrial Automation Parts
Key specifications
- Function
- Quick Response Type (0.95W)+Negative Common
- Coil Voltage
- 24 VDC
- Product description
- VQC2000 Series 5 Port Solenoid Valve Base Mounted Plug-in Unit How To Order Valve
- Light/Surge Voltage Suppressor
- Yes
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The SMC VQC2400BN-51 is a VQC2000 series 5-port plug-in solenoid valve for base-mounted manifolds, in the 3-position exhaust center version with a metal seal. This model has the high-speed response function (0.95 W) with negative common wiring, a 24 VDC coil, a built-in light/surge voltage suppressor and a non-locking push manual override. It operates from 0.1 to 0.7 MPa, with a flow rate of C 2.0 dm3/(s·bar) (Cv 0.46) from P to A/B and a response time of 29 ms or less. The enclosure is IP67 compatible and the valve weighs 105 g.
Technical reference
| Product name | SMC VQC2400BN-51 Solenoid Valve |
|---|---|
| Brand | SMC |
| Model | VQC2400BN-51 |
| Category | Industrial Automation Parts |
| Function | Quick Response Type (0.95W)+Negative Common |
| Coil Voltage | 24 VDC |
| Product description | VQC2000 Series 5 Port Solenoid Valve Base Mounted Plug-in Unit How To Order Valve |
| Light/Surge Voltage Suppressor | Yes |
