SMC SY5220-5DZ-C8 SY5000 Series 5 Port Solenoid Valve
- Brand
- SMC
- Model
- SY5220-5DZ-C8
- GEARWELL SKU
- GWP-000020962
- Category
- Valves & Manifolds
Key specifications
- Series
- SY5000 (code 5)
- Thread Type
- Rc
- A/B Port Size
- One-touch Fitting For Φ8 (code C8)
- Rated Voltage
- 24 VDC (code 5)
- Manual Override
- Push-turn Locking Type
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC SY5220-5DZ-C8 SY5000 Series 5 Port Solenoid Valve |
|---|---|
| Brand | SMC |
| Model | SY5220-5DZ-C8 |
| Category | Valves & Manifolds |
| Series | SY5000 (code 5) |
| Thread Type | Rc |
| A/B Port Size | One-touch Fitting For Φ8 (code C8) |
| Rated Voltage | 24 VDC (code 5) |
| Manual Override | Push-turn Locking Type |
| Electrical Entry | DIN Terminal (code D) |
| Type Of Actuation | 2 Position Double (code 2) |
| Coil Specifications | Standard |
| Light/Surge Voltage Suppressor | With Light/Surge Voltage Suppressor (code Z) |
