FESTO 537983 VMPA2-FB-EMS-4 Valve Terminal Electronics Module
- Brand
- FESTO
- Model
- 537983
- GEARWELL SKU
- GWP-000023662
- Category
- Valves & Manifolds
Key specifications
- Diagnostics
- Undervoltage of pneumatic valves
- Part number
- 537983
- Product weight
- 20 g
- Type designation
- VMPA2-FB-EMS-4
- Max. no. of solenoid coils
- 4
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO 537983 VMPA2-FB-EMS-4 Valve Terminal Electronics Module |
|---|---|
| Brand | FESTO |
| Model | 537983 |
| Category | Valves & Manifolds |
| Diagnostics | Undervoltage of pneumatic valves |
| Part number | 537983 |
| Product weight | 20 g |
| Type designation | VMPA2-FB-EMS-4 |
| Max. no. of solenoid coils | 4 |
| Max. no. of valve positions | 2 |
| Nominal current with current reduction | 18 mA after 24 ms |
| Nominal pick-up current per solenoid coil | 99 mA up to 24 ms |
| Intrinsic current consumption at load voltage | 3 mA |
| Intrinsic current consumption at operating voltage | 8 mA |
