SMC SV4200-5FUD Solenoid Valves
- Brand
- SMC
- Model
- SV4200-5FUD
- GEARWELL SKU
- GWP-000003844
- Category
- Industrial Automation Parts
Key specifications
- Rated Voltage
- 24 VDC
- Product description
- SV Series Solenoid Valves
- Back Pressure Check Valve
- None
- Light/Surge Voltage Suppressor
- With Light/Surge Voltage Suppressor
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The SMC SV4200-5FUD is an SV4000 series 5-port solenoid valve for manifold mounting, 2-position double solenoid with an internal pilot. It has a 24 V DC coil with a light/surge voltage suppressor and a push-turn locking slotted manual override. The valve operates from 0.1 to 0.7 MPa, at up to 5 Hz, with a response time of 40 ms or less. Power consumption is 0.65 W with the indicator light, the enclosure is IP67 and the valve weighs 190 g.
Technical reference
| Product name | SMC SV4200-5FUD Solenoid Valves |
|---|---|
| Brand | SMC |
| Model | SV4200-5FUD |
| Category | Industrial Automation Parts |
| Rated Voltage | 24 VDC |
| Product description | SV Series Solenoid Valves |
| Back Pressure Check Valve | None |
| Light/Surge Voltage Suppressor | With Light/Surge Voltage Suppressor |
