SMC CQ2KB16-25DM Compact Non-rotating Pneumatic Cylinder
- Brand
- SMC
- Model
- CQ2KB16-25DM
- GEARWELL SKU
- GWP-000006358
- Category
- Cylinders & Actuators
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The SMC CQ2KB16-25DM is a CQ2K series compact air cylinder with a non-rotating piston rod, a 16 mm bore and a 25 mm stroke, double acting with a single rod. It uses the through-hole (standard) mounting style, M5 x 0.8 ports and a male-threaded rod end, and has no built-in magnet for auto switches. The maximum operating pressure is 1.0 MPa (proof pressure 1.5 MPa) and the piston speed range is 50 to 500 mm/s. No lubrication is required.
Technical reference
| Product name | SMC CQ2KB16-25DM Compact Non-rotating Pneumatic Cylinder |
|---|---|
| Brand | SMC |
| Model | CQ2KB16-25DM |
| Category | Cylinders & Actuators |
