SICK 6060573 LBV331-CXBNTNVNX0727 Vibrating Level Switch
- Brand
- SICK
- Model
- 6060573
- GEARWELL SKU
- GWP-000013875
- Category
- Pressure, Flow & Temperature
Key specifications
- Length
- 727 mm
- Output
- NAMUR output
- Version
- With middle section (temperature adapter), tube extension
- Article number
- 6060573
- Wetted material
- 316L, Ra < 0.8 µm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 6060573 LBV331-CXBNTNVNX0727 Vibrating Level Switch |
|---|---|
| Brand | SICK |
| Model | 6060573 |
| Category | Pressure, Flow & Temperature |
| Length | 727 mm |
| Output | NAMUR output |
| Version | With middle section (temperature adapter), tube extension |
| Article number | 6060573 |
| Wetted material | 316L, Ra < 0.8 µm |
| Type designation | LBV331-CXBNTNVNX0727 |
| Process connection | Thread 1 1/2" NPT (ASME B1.20.1), PN16 |
| Process temperature | -50 ... +250 °C |
| Explosion protection | ATEX II 1G, 1/2G, 2G Ex ia IIC T6 (TÜV 10 ATEX 389904 X) |
| Housing material / enclosure | Stainless steel 316L (precision casting); IP66, IP67 (IP68, 0.2 bar); cable entry 1/2" NPT |
