SICK 6052218 TCT-1AAGE0503LZ Resistance Thermometer
- Brand
- SICK
- Model
- 6052218
- GEARWELL SKU
- GWP-000022880
- Category
- Pressure, Flow & Temperature
Key specifications
- Output signal
- Transmitter 4...20 mA, 2-wire
- Article number
- 6052218
- Connection type
- L-connector (DIN EN 175301-803 A)
- Enclosure rating
- IP65
- Type designation
- TCT-1AAGE0503LZ
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 6052218 TCT-1AAGE0503LZ Resistance Thermometer |
|---|---|
| Brand | SICK |
| Model | 6052218 |
| Category | Pressure, Flow & Temperature |
| Output signal | Transmitter 4...20 mA, 2-wire |
| Article number | 6052218 |
| Connection type | L-connector (DIN EN 175301-803 A) |
| Enclosure rating | IP65 |
| Type designation | TCT-1AAGE0503LZ |
| Code as collected | 6052218 (seller title: [待拆] TCT-1AAGE0503LZ Sick 西克 温湿度产品) |
| Process connection | Thread G 1/2 B |
| Temperature measuring range | -50 ... +150 °C |
| Insertion length / probe diameter | 50 mm / 3 mm |
