SICK 6044871 LBV321-XXTGCNKMX01000 LBV321 Vibrating Level Switch
- Brand
- SICK
- Model
- 6044871
- GEARWELL SKU
- GWP-000020743
- Category
- Pressure, Flow & Temperature
Key specifications
- Medium
- Bulk solids
- Hysteresis
- 10 mm
- Probe type
- Rod probe
- Cable entry
- M20 x 1.5
- Probe length
- 1,000 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 6044871 LBV321-XXTGCNKMX01000 LBV321 Vibrating Level Switch |
|---|---|
| Brand | SICK |
| Model | 6044871 |
| Category | Pressure, Flow & Temperature |
| Medium | Bulk solids |
| Hysteresis | 10 mm |
| Probe type | Rod probe |
| Cable entry | M20 x 1.5 |
| Probe length | 1,000 mm |
| Wetted parts | Stainless steel 1.4404 / 316L |
| Output signal | NAMUR signal |
| Article number | 6044871 |
| Supply voltage | 4.5 ... 12 V DC |
| Enclosure rating | IP66, IP67 |
| Housing material | Plastic |
| Process pressure | -1 ... 6 bar |
| Type designation | LBV321-XXTGCNKMX01000 |
| Process connection | G 1, DIN 3852-A, PN 6 / 316L |
| Process temperature | -20 ... +80 °C |
