SICK 6043349 TCT-1ABS21006LZ TCT Temperature Transmitter
- Brand
- SICK
- Model
- 6043349
- GEARWELL SKU
- GWP-000020742
- Category
- Pressure, Flow & Temperature
Key specifications
- Wetted parts
- Stainless steel 1.4571
- Output signal
- 4 ... 20 mA, 2-wire
- Article number
- 6043349
- Sensor element
- Pt1000, class A (IEC 60751)
- Supply voltage
- 10 ... 35 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SICK 6043349 TCT-1ABS21006LZ TCT Temperature Transmitter |
|---|---|
| Brand | SICK |
| Model | 6043349 |
| Category | Pressure, Flow & Temperature |
| Wetted parts | Stainless steel 1.4571 |
| Output signal | 4 ... 20 mA, 2-wire |
| Article number | 6043349 |
| Sensor element | Pt1000, class A (IEC 60751) |
| Supply voltage | 10 ... 35 V DC |
| Connection type | L-connector (DIN EN 175301-803 A), 4-pin |
| Measuring range | -50 ... +250 °C |
| Enclosure rating | IP65 |
| Type designation | TCT-1ABS21006LZ |
| Process connection | compression fitting ½'' NPT, CrNi stainless steel ferrule |
| Transmitter accuracy | ≤ ±0.2 % of span |
| Maximum process pressure | ≤ 100 bar |
| Insertion length / probe diameter | 100 / 6 mm |
