Setra SRH13PF2CT2N SRH Humidity Transmitter
- Brand
- Setra
- Model
- SRH13PF2CT2N
- GEARWELL SKU
- GWP-000022220
- Category
- Pressure, Flow & Temperature
Key specifications
- Display (N)
- None
- Output (2C)
- 0 to 5 or 0 to 10 VDC, user selectable (3-wire)
- Model code
- SRH1 (Model SRH)
- Accuracy (3P)
- ±3 % RH
- Sensing element
- Capacitive polymer
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra SRH13PF2CT2N SRH Humidity Transmitter |
|---|---|
| Brand | Setra |
| Model | SRH13PF2CT2N |
| Category | Pressure, Flow & Temperature |
| Display (N) | None |
| Output (2C) | 0 to 5 or 0 to 10 VDC, user selectable (3-wire) |
| Model code | SRH1 (Model SRH) |
| Accuracy (3P) | ±3 % RH |
| Sensing element | Capacitive polymer |
| Configuration options | W Wall / D Duct / O Outside Air (specify on order) |
| Operating temperature | -40 to 60 °C |
| Temperature output (T2) | 1000 Ω RTD (passive) |
| Humidity operating range | 0 to 99 (non-condensing) % RH |
| Code suffix "F" (configuration position) | as collected; not listed in the official model-number table (W wall / D duct / O outside air) |
