Schneider Electric XCSTA791 Telemecanique Safety switches XCS Safety switch
- Brand
- Schneider Electric
- Model
- XCSTA791
- GEARWELL SKU
- GWP-000017737
- Category
- Machine Safety & Vision
Key specifications
- Design
- Compact
- Material
- Plastic
- Head type
- Key operated turret head
- Insulation
- Double insulated
- Cable entry
- 2 entries tapped for Pg 11
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric XCSTA791 Telemecanique Safety switches XCS Safety switch |
|---|---|
| Brand | Schneider Electric |
| Model | XCSTA791 |
| Category | Machine Safety & Vision |
| Design | Compact |
| Material | Plastic |
| Head type | Key operated turret head |
| Insulation | Double insulated |
| Cable entry | 2 entries tapped for Pg 11 |
| Component name | XCSTA |
| Number of poles | 3 |
| Positive opening | With NC contact |
| Contact operation | Slow-break, break before make |
| Cable outer diameter | 7…10 Mm |
| Electrical connection | Terminal, clamping capacity: 1 x 0.5...2 x 1.5 mm² with or without cable end |
| Mechanical durability | 1000000 Cycles |
| Maximum actuation speed | 0.5 M/S |
| Minimum actuation speed | 0.01 M/S |
| Locking options description | Without locking of actuator |
| [Ui] rated insulation voltage | 300 V conforming to UL 508 / 500 V conforming to IEC 60947-1 / 300 V conforming to CSA C22.2 No 14 |
| [Ie] rated operational current | 6 A at 120 V, AC-15, A300 conforming to IEC 60947-5-1 / 3 A at 240 V, AC-15, A300 conforming to IEC 60947-5-1 / 0.55 A at 125 V, DC-13, Q300 conforming to IEC 60947-5-1 / 0.27 A at 250 V, DC-13, Q300 conforming to IEC 60947-5-1 |
| Contacts type and composition | 2 NC + 1 NO |
| Positive opening minimum force | 15 N |
| [Uimp] rated impulse withstand voltage | 6 KV conforming to IEC 60947-5-1 |
