Schneider Electric XCKN2118P20 Telemecanique Limit switches XC Standard Limit switch
- Brand
- Schneider Electric
- Model
- XCKN2118P20
- GEARWELL SKU
- GWP-000017736
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Tracks
- 24/40 mm
- Material
- Plastic
- Body type
- Fixed
- Head type
- Rotary head
- Cable entry
- 1 entry tapped for M20 x 1.5 cable gland, cable outer diameter: 7…13 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric XCKN2118P20 Telemecanique Limit switches XC Standard Limit switch |
|---|---|
| Brand | Schneider Electric |
| Model | XCKN2118P20 |
| Category | Proximity & Photoelectric Sensors |
| Tracks | 24/40 mm |
| Material | Plastic |
| Body type | Fixed |
| Head type | Rotary head |
| Cable entry | 1 entry tapped for M20 x 1.5 cable gland, cable outer diameter: 7…13 mm |
| Fixing mode | By the body |
| Series name | Standard format |
| Body material | Plastic |
| Head material | Plastic |
| Sensor design | Compact form A |
| Number of poles | 2 |
| Switch actuation | By 30° cam |
| Type of approach | Lateral approach, 2 directions |
| Type of operator | Spring return roller lever thermoplastic |
| Contact operation | Snap action |
| Device short name | XCKN |
| Electrical connection | Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mm² |
| Contacts insulation form | Zb |
| Movement of operating head | Rotary |
| Contacts type and composition | 1 NC + 1 NO |
