Schneider Electric TM221M16R Modicon M221 Logic Controller
- Brand
- Schneider Electric
- Model
- TM221M16R
- GEARWELL SKU
- GWP-000007414
- Category
- PLCs & I/O
Key specifications
- Discrete I/O number
- 16
- Discrete output type
- Relay normally open
- Analogue input number
- 2 at 0...10 V
- Discrete input number
- 8, discrete input conforming to IEC 61131-2 Type 1
- Discrete output number
- 8 relay
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Schneider Electric TM221M16R is a Modicon M221 Book logic controller with 16 I/O: 8 sink/source 24 V DC inputs incl. 4 high-speed inputs, 8 relay outputs; 2 analog inputs 0–10 V; 24 V DC power supply; serial links SL1 and SL2 (RJ45); removable screw terminal blocks. It is programmed with EcoStruxure Machine Expert - Basic through its mini-B USB port, has a slot for an industrial SD memory card, and connects to Modicon TM3 expansion modules through its TM3 bus connector.
Technical reference
| Product name | Schneider Electric TM221M16R Modicon M221 Logic Controller |
|---|---|
| Brand | Schneider Electric |
| Model | TM221M16R |
| Category | PLCs & I/O |
| Discrete I/O number | 16 |
| Discrete output type | Relay normally open |
| Analogue input number | 2 at 0...10 V |
| Discrete input number | 8, discrete input conforming to IEC 61131-2 Type 1 |
| Discrete output number | 8 relay |
| Discrete output current | 2A |
| Discrete output voltage | 5...125 V DC, 5...250 V AC |
| [Us] rated supply voltage | 24 V DC |
