Schneider Electric BMH1402P16F2A Lexium 32 Servo motor
- Brand
- Schneider Electric
- Model
- BMH1402P16F2A
- GEARWELL SKU
- GWP-000013003
- Category
- Servo Systems
Key specifications
- Shaft end
- Keyed
- Holding brake
- With
- Nominal speed
- 3000 rpm for LXM32.D72N4 at 24 A, 400 V, three phase ; 3000 rpm for LXM32.D72N4 at 24 A, 480 V, three phase
- Nominal output power
- 3500 W for LXM32.D72N4 at 24 A, 400 V, three phase ; 3500 W for LXM32.D72N4 at 24 A, 480 V, three phase
- Continuous stall torque
- 18.5 N.M for LXM32.D72N4 at 24 A, 400 V, three phase ; 18.5 N.M for LXM32.D72N4 at 24 A, 480 V, three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BMH1402P16F2A Lexium 32 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BMH1402P16F2A |
| Category | Servo Systems |
| Shaft end | Keyed |
| Holding brake | With |
| Nominal speed | 3000 rpm for LXM32.D72N4 at 24 A, 400 V, three phase ; 3000 rpm for LXM32.D72N4 at 24 A, 480 V, three phase |
| Nominal output power | 3500 W for LXM32.D72N4 at 24 A, 400 V, three phase ; 3500 W for LXM32.D72N4 at 24 A, 480 V, three phase |
| Continuous stall torque | 18.5 N.M for LXM32.D72N4 at 24 A, 400 V, three phase ; 18.5 N.M for LXM32.D72N4 at 24 A, 480 V, three phase |
| IP degree of protection | IP54 standard |
| Maximum mechanical speed | 4000 rpm |
| Speed feedback resolution | 32768 points/turn |
