Schneider Electric ATV930D22N4 Altivar Process ATV900 Variable speed drive
- Brand
- Schneider Electric
- Model
- ATV930D22N4
- GEARWELL SKU
- GWP-000031849
- Category
- Variable Frequency Drives
Key specifications
- Variant
- Standard version ; With braking chopper
- Motor power kW
- 22.0 KW for normal duty ; 18.5 KW for heavy duty
- Range of product
- Altivar Process ATV900
- Nominal output current
- 46.3 A
- IP degree of protection
- IP21
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric ATV930D22N4 Altivar Process ATV900 Variable speed drive |
|---|---|
| Brand | Schneider Electric |
| Model | ATV930D22N4 |
| Category | Variable Frequency Drives |
| Variant | Standard version ; With braking chopper |
| Motor power kW | 22.0 KW for normal duty ; 18.5 KW for heavy duty |
| Range of product | Altivar Process ATV900 |
| Nominal output current | 46.3 A |
| IP degree of protection | IP21 |
| [Us] rated supply voltage | 380...480 V - 15...10 % |
| Continuous output current | 46.3 A at 4 kHz for normal duty ; 39.2 A at 4 kHz for heavy duty |
| Product or component type | Variable speed drive |
