Schneider Electric ATV61WD18N4 Altivar 61 Variable speed drive

Key specifications

Phase: 3 phase
EMC filter: Class C2 EMC filter integrated
Line current: 32.3 A 480 V 3 phase 18.5 kW / 25 hp; 37.5 A 380 V 3 phase 18.5 kW / 25 hp
Apparent power: 24.7 KVA 380 V 3 phase 18.5 kW / 25 hp
Assembly style: Enclosed

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Schneider Electric ATV61WD18N4 Altivar 61 Variable speed drive
Brand	Schneider Electric
Model	ATV61WD18N4
Category	Variable Frequency Drives
Phase	3 phase
EMC filter	Class C2 EMC filter integrated
Line current	32.3 A 480 V 3 phase 18.5 kW / 25 hp; 37.5 A 380 V 3 phase 18.5 kW / 25 hp
Apparent power	24.7 KVA 380 V 3 phase 18.5 kW / 25 hp
Assembly style	Enclosed
Motor power kW	18.5 KW, 3 phase 380...480 V
Range of Product	Altivar 61
Prospective line Isc	22 KA 3 phase
[Us] rated supply voltage	380...480 V - 15...10 %
Product or Component Type	Variable speed drive
Maximum Horse Power Rating	25 Hp, 3 phase 380...480 V
Product Specific Application	Pumping and ventilation machine
