Schneider Electric ATV71HU40N4Z Altivar 71 Variable speed drive
- Brand
- Schneider Electric
- Model
- ATV71HU40N4Z
- GEARWELL SKU
- GWP-000012993
- Category
- Variable Frequency Drives
Key specifications
- Version
- Without remote graphic terminal
- EMC filter
- Integrated
- Line current
- 11.5 A at 480 V ; 14.1 A at 380 V
- Apparent power
- 9.3 kVA at 380 V
- Motor power kW
- 4 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric ATV71HU40N4Z Altivar 71 Variable speed drive |
|---|---|
| Brand | Schneider Electric |
| Model | ATV71HU40N4Z |
| Category | Variable Frequency Drives |
| Version | Without remote graphic terminal |
| EMC filter | Integrated |
| Line current | 11.5 A at 480 V ; 14.1 A at 380 V |
| Apparent power | 9.3 kVA at 380 V |
| Motor power kW | 4 kW |
| Nominal output current | 10.5 A at 4 kHz 380 V ; 7.6 A at 4 kHz 460 V |
| [Us] rated supply voltage | 380...480 V - 15...10 % |
| Network number of phases | 3 phases |
