Schneider Electric 140DAO84210 Modicon Quantum automation platform Discrete output module

Brand: Schneider Electric
Model: 140DAO84210
GEARWELL SKU: GWP-000017297
Category: PLCs & I/O

Key specifications

DV/dt: 400 V/ms
Net weight: 0.45 Kg
Response time: <= 0.5 ms at state 0 to state 1 / <= 0.5 ms at state 1 to state 0
Surge current: 10 A during 3 cycles per point / 20 A during 2 cycles per point / 30 A during 1 cycle per point / 25 A during 3 cycles per group / 30 A during 2 cycles per group / 45 A during 1 cycle per group
Protection type: Internal by RC filter / Internal output protection by 5 A fuse

Request a QuoteWhatsApp

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

← Back to products

Technical reference

Product name	Schneider Electric 140DAO84210 Modicon Quantum automation platform Discrete output module
Brand	Schneider Electric
Model	140DAO84210
Category	PLCs & I/O
DV/dt	400 V/ms
Net weight	0.45 Kg
Response time	<= 0.5 ms at state 0 to state 1 / <= 0.5 ms at state 1 to state 0
Surge current	10 A during 3 cycles per point / 20 A during 2 cycles per point / 30 A during 1 cycle per point / 25 A during 3 cycles per group / 30 A during 2 cycles per group / 45 A during 1 cycle per group
Protection type	Internal by RC filter / Internal output protection by 5 A fuse
Fault indication	Blown fuse / Loss of field power
Supply frequency	47...63 Hz
Group of channels	4 groups of 4 channels
Power dissipation	1.85 + (1.1 V x total module load current)
Maximum load current	2 mA rms 115 Vrms off state leakage per output / 2.5 mA rms 230 Vrms off state leakage per output / 3 A rms 170...253 V per output / 4 A rms 85...132 V per output / 16 A rms per module / 4 A rms per group
Maximum voltage drop	1.5 V
Addressing requirement	1 output word
Discrete output number	16
Absolute maximum output	300 Vrms for 10 s AC / 400 Vrms 1 cycle AC
Bus current requirement	350 MA
Discrete output voltage	83...253 V AC
