SAMKOON GT-043-16MT GT Series 4.3-inch HMI PLC All-in-One Unit
- Brand
- SAMKOON
- Model
- GT-043-16MT
- GEARWELL SKU
- GWP-000023786
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- Cortex-A7 dual-core 1 GHz
- Memory
- 128 MB DDR / 128 MB flash
- Display
- 4.3" (16:9), 480 x 272, 16.7 million colours
- Protection
- IP65 (front panel)
- Power supply
- 24 V DC +/-15%
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SAMKOON GT-043-16MT GT Series 4.3-inch HMI PLC All-in-One Unit |
|---|---|
| Brand | SAMKOON |
| Model | GT-043-16MT |
| Category | HMIs & Industrial PCs |
| CPU | Cortex-A7 dual-core 1 GHz |
| Memory | 128 MB DDR / 128 MB flash |
| Display | 4.3" (16:9), 480 x 272, 16.7 million colours |
| Protection | IP65 (front panel) |
| Power supply | 24 V DC +/-15% |
| Communication | RS485 (HMI) + RS485 (PLC); no Ethernet |
| Digital inputs | 8 |
| Digital outputs | 8 transistor, incl. 4 high-speed pulse outputs up to 200 kHz |
| Dimensions / cut-out | 147 x 90 x 40 mm / 141 x 84 mm |
