SAMKOON EA-043A-Q EA Series 4.3-inch HMI Touch Panel
- Brand
- SAMKOON
- Model
- EA-043A-Q
- GEARWELL SKU
- GWP-000024046
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- Dual-core Cortex-A7, up to 1 GHz
- Memory
- 128 MB DDR3 + 128 MB flash
- Display
- 4.3 in, 480 x 272, 16.77 million colours, 400 cd/m2
- Software
- SATOOL
- Touch panel
- 4-wire resistive
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SAMKOON EA-043A-Q EA Series 4.3-inch HMI Touch Panel |
|---|---|
| Brand | SAMKOON |
| Model | EA-043A-Q |
| Category | HMIs & Industrial PCs |
| CPU | Dual-core Cortex-A7, up to 1 GHz |
| Memory | 128 MB DDR3 + 128 MB flash |
| Display | 4.3 in, 480 x 272, 16.77 million colours, 400 cd/m2 |
| Software | SATOOL |
| Touch panel | 4-wire resistive |
| Communication | RS232 / RS422 / RS485, USB download, USB-disk update |
| Front protection | IP65 |
| Dimensions / cut-out | 138 x 86 x 38 / 132 x 80 mm |
| Operating temperature | -20 to 55 degC |
