RKC FR-100-DPA-42-A-250-5000-N-AW PFA-Coated Pt100 Sensor
- Brand
- RKC
- Model
- FR-100-DPA-42-A-250-5000-N-AW
- GEARWELL SKU
- GWP-000022700
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy
- ±(0.15+0.002|t|) °C
- Cleaning
- AW: pure water cleaning & clean packing
- Input type
- DPA: Pt100 Class A
- Cable terminal
- N: no terminal
- Measuring range
- 0 to 200 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | RKC FR-100-DPA-42-A-250-5000-N-AW PFA-Coated Pt100 Sensor |
|---|---|
| Brand | RKC |
| Model | FR-100-DPA-42-A-250-5000-N-AW |
| Category | Pressure, Flow & Temperature |
| Accuracy | ±(0.15+0.002|t|) °C |
| Cleaning | AW: pure water cleaning & clean packing |
| Input type | DPA: Pt100 Class A |
| Cable terminal | N: no terminal |
| Measuring range | 0 to 200 °C |
| Coating material | A: PFA |
| Lead wire length | 5000 mm |
| Lead wire diameter | ø1.7 mm |
| Protection tube length | 250 mm |
| Protection tube diameter | 42: ø4 mm |
