PILZ PSEN 1.2p-22/8mm/ix1/1 PSENmag Magnetic Safety Switch
- Brand
- PILZ
- Model
- PSEN 1.2p-22/8mm/ix1/1
- GEARWELL SKU
- GWP-000015343
- Category
- Machine Safety & Vision
Key specifications
- Design
- Round, M30
- Actuator
- PSEN 1.2-20
- Connection
- M8, 4-pin male
- Supply voltage
- 24 V DC
- Sensor principle
- Magnetic
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PILZ PSEN 1.2p-22/8mm/ix1/1 PSENmag Magnetic Safety Switch |
|---|---|
| Brand | PILZ |
| Model | PSEN 1.2p-22/8mm/ix1/1 |
| Category | Machine Safety & Vision |
| Design | Round, M30 |
| Actuator | PSEN 1.2-20 |
| Connection | M8, 4-pin male |
| Supply voltage | 24 V DC |
| Sensor principle | Magnetic |
| Switching distance | 8 mm |
| Ambient temperature | -10 to 55 °C |
| Coding level (ISO 14119) | Low |
