PILZ PNOZ XV1P 3/24VDC 2n/o 1n/o t Safety Relay
- Brand
- PILZ
- Model
- PNOZ XV1P 3/24VDC 2n/o 1n/o t
- GEARWELL SKU
- GWP-000015342
- Category
- Machine Safety & Vision
Key specifications
- Weight
- 230 g
- Delay range
- up to 3 s, selectable
- Order number
- 777601 (screw terminals)
- Safety level
- up to PL e (EN ISO 13849-1)
- Supply voltage
- 24 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PILZ PNOZ XV1P 3/24VDC 2n/o 1n/o t Safety Relay |
|---|---|
| Brand | PILZ |
| Model | PNOZ XV1P 3/24VDC 2n/o 1n/o t |
| Category | Machine Safety & Vision |
| Weight | 230 g |
| Delay range | up to 3 s, selectable |
| Order number | 777601 (screw terminals) |
| Safety level | up to PL e (EN ISO 13849-1) |
| Supply voltage | 24 V DC |
| Safety contacts | 2 N/O instantaneous, 1 N/O delayed |
| Power consumption | 3.5 W |
| Dimensions (H x W x D) | 94 x 22.5 x 121 mm |
