PILZ 777314 PNOZ X3.10P 24VACDC 3n/o 1n/c 1so Safety Relay
- Brand
- PILZ
- Model
- 777314
- GEARWELL SKU
- GWP-000015340
- Category
- Machine Safety & Vision
Key specifications
- Width
- 45 mm
- Outputs
- 3 N/O, 1 N/C, 1 semiconductor
- Terminals
- Plug-in screw terminals
- Contact rating
- 8 A (AC1 240 V / DC1 24 V)
- Supply voltage
- 24 V AC/DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PILZ 777314 PNOZ X3.10P 24VACDC 3n/o 1n/c 1so Safety Relay |
|---|---|
| Brand | PILZ |
| Model | 777314 |
| Category | Machine Safety & Vision |
| Width | 45 mm |
| Outputs | 3 N/O, 1 N/C, 1 semiconductor |
| Terminals | Plug-in screw terminals |
| Contact rating | 8 A (AC1 240 V / DC1 24 V) |
| Supply voltage | 24 V AC/DC |
| Type designation | PNOZ X3.10P 24VACDC 3n/o 1n/c 1so |
| Power consumption | 5 VA AC / 2.5 W DC |
