PILZ 774070 PNOZ 16S 24VAC 24VDC Safety Relay
- Brand
- PILZ
- Model
- 774070
- GEARWELL SKU
- GWP-000015338
- Category
- Machine Safety & Vision
Key specifications
- Terminals
- Screw terminals
- Contact rating
- 8 A (AC1 240 V / DC1 24 V)
- Supply voltage
- 24 V AC; 24 V DC
- Safety contacts
- 2 N/O, instantaneous
- Type designation
- PNOZ 16S 24VAC 24VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PILZ 774070 PNOZ 16S 24VAC 24VDC Safety Relay |
|---|---|
| Brand | PILZ |
| Model | 774070 |
| Category | Machine Safety & Vision |
| Terminals | Screw terminals |
| Contact rating | 8 A (AC1 240 V / DC1 24 V) |
| Supply voltage | 24 V AC; 24 V DC |
| Safety contacts | 2 N/O, instantaneous |
| Type designation | PNOZ 16S 24VAC 24VDC |
| Ambient temperature | -10 to 55 °C |
| Semiconductor outputs | 2 (24 V, 20 mA) |
| Protection (housing / terminals) | IP40 / IP20 |
