Phoenix Contact 2810489 MINI MCR-BL-PT100-I-NC Temperature Transducer
- Brand
- Phoenix Contact
- Model
- 2810489
- GEARWELL SKU
- GWP-000017051
- Category
- Pressure, Flow & Temperature
Key specifications
- Order number
- 2810489
- Product type
- Temperature transmitter
- Product family
- ESSENTIAL edition
- Type designation
- MINI MCR-BL-PT100-I-NC
- Code as collected
- MINI MCR-BL-PT100-I-NC PHOENIX CONTACT 菲尼克斯 温湿度产品
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Phoenix Contact 2810489 MINI MCR-BL-PT100-I-NC Temperature Transducer |
|---|---|
| Brand | Phoenix Contact |
| Model | 2810489 |
| Category | Pressure, Flow & Temperature |
| Order number | 2810489 |
| Product type | Temperature transmitter |
| Product family | ESSENTIAL edition |
| Type designation | MINI MCR-BL-PT100-I-NC |
| Code as collected | MINI MCR-BL-PT100-I-NC PHOENIX CONTACT 菲尼克斯 温湿度产品 |
| Connection method | Screw connection |
| Supply voltage range | 19.2 V DC ... 30 V DC |
| Current output signal | 0 mA ... 20 mA |
| Temperature measuring range | -50 °C ... 200 °C |
| Sensor types (RTD) that can be used | Pt 100 (IEC 60751/EN 60751) |
