Pepperl+Fuchs LVL-T1-G3S-E5PG-NA Vibracon Vibration Limit Switch
- Brand
- Pepperl+Fuchs
- Model
- LVL-T1-G3S-E5PG-NA
- GEARWELL SKU
- GWP-000022729
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- E5, PNP, max. 350 mA continuous
- Weight
- approx. 450 g
- Density
- min. 0.7 g/cm3
- Version
- G1, 1.4571, 10 ... 55 V DC, PNP 3-wire, connector PG11
- Supply voltage
- 10 ... 55 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Pepperl+Fuchs LVL-T1-G3S-E5PG-NA Vibracon Vibration Limit Switch |
|---|---|
| Brand | Pepperl+Fuchs |
| Model | LVL-T1-G3S-E5PG-NA |
| Category | Pressure, Flow & Temperature |
| Output | E5, PNP, max. 350 mA continuous |
| Weight | approx. 450 g |
| Density | min. 0.7 g/cm3 |
| Version | G1, 1.4571, 10 ... 55 V DC, PNP 3-wire, connector PG11 |
| Supply voltage | 10 ... 55 V DC |
| Process pressure | -1 ... +40 bar |
| Protection class | IP65/IP67 with connector PG11 |
| Medium temperature | -40 ... +150 °C |
| Related order code | LVL-T1-G3S-E5PG-NA-EMS (part no. 262209) exists as separate archived item |
