PANASONIC MCDHT3520 MINAS A5 C-Frame AC Servo Driver
- Brand
- PANASONIC
- Model
- MCDHT3520
- GEARWELL SKU
- GWP-000021513
- Category
- Servo Systems
Key specifications
- Mass
- 1.6 kg
- Type
- Speed, position, torque, full-closed
- Frame
- C-frame
- Series
- MINAS A5 (A5 series)
- Encoder
- 17-bit absolute / 20-bit incremental
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC MCDHT3520 MINAS A5 C-Frame AC Servo Driver |
|---|---|
| Brand | PANASONIC |
| Model | MCDHT3520 |
| Category | Servo Systems |
| Mass | 1.6 kg |
| Type | Speed, position, torque, full-closed |
| Frame | C-frame |
| Series | MINAS A5 (A5 series) |
| Encoder | 17-bit absolute / 20-bit incremental |
| Interface | Analog/pulse |
| Lifecycle | Discontinued |
| Safety function | With |
| Main circuit supply | Single/3-phase 200-240 V AC, 50/60 Hz |
| Dimensions (W x H x D) | 65 x 150 x 170 mm |
