PANASONIC EX-21A EX-20 Ultra-compact Thru-beam Photoelectric Sensor
- Brand
- PANASONIC
- Model
- EX-21A
- GEARWELL SKU
- GWP-000021507
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Output
- NPN open-collector, max. 50 mA
- Connection
- 2 m cabtyre cable
- Protection
- IP67 (IEC)
- Response time
- 0.5 or less ms
- Sensing range
- 1 m
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC EX-21A EX-20 Ultra-compact Thru-beam Photoelectric Sensor |
|---|---|
| Brand | PANASONIC |
| Model | EX-21A |
| Category | Proximity & Photoelectric Sensors |
| Output | NPN open-collector, max. 50 mA |
| Connection | 2 m cabtyre cable |
| Protection | IP67 (IEC) |
| Response time | 0.5 or less ms |
| Sensing range | 1 m |
| Sensing method | Thru-beam, front sensing |
| Supply voltage | 12 to 24 ±10 % VDC |
| Emitting element | Red LED, 640 nm |
| Min. sensing object | ø2.6 opaque mm |
