PANASONIC AKW5112 KW4M Eco-POWER METER
- Brand
- PANASONIC
- Model
- AKW5112
- GEARWELL SKU
- GWP-000022609
- Category
- Test & Measurement
Key specifications
- Protection
- IP66 (front panel with rubber gasket)
- Part number
- AKW5112
- Rated frequency
- 50/60 Hz common
- Phase and wire system
- Single-phase two-wire / single-phase three-wire / three-phase three-wire (common)
- Rated operating voltage
- 100-120/200-240 V AC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC AKW5112 KW4M Eco-POWER METER |
|---|---|
| Brand | PANASONIC |
| Model | AKW5112 |
| Category | Test & Measurement |
| Protection | IP66 (front panel with rubber gasket) |
| Part number | AKW5112 |
| Rated frequency | 50/60 Hz common |
| Phase and wire system | Single-phase two-wire / single-phase three-wire / three-phase three-wire (common) |
| Rated operating voltage | 100-120/200-240 V AC |
| Rated power consumption | 8 VA |
| CT primary rating (dedicated CT) | 5A/50A/100A/250A/400A (select with setting mode) |
