OMRON R88D-KN02H-ECT OMNUC G5 / Accurax G5 AC servo drive, EtherCAT
- Brand
- OMRON
- Model
- R88D-KN02H-ECT
- GEARWELL SKU
- GWP-000012766
- Category
- Servo Systems
Key specifications
- Network
- EtherCAT
- Weight (approx.)
- 0.8 kg
- Control circuit power supply
- Single-phase 200-240 VAC
- Continuous output current (rms)
- 1.6 A
- Max. applicable motor capacity
- 200 W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON R88D-KN02H-ECT is an Accurax G5 servo drive with EtherCAT communications for 200 W servo motors, such as the R88M-K20030 (0.64 Nm, 3000 min-1) and the high inertia R88M-KH20030. Continuous output current is 1.6 Arms. The main circuit takes single-phase/3-phase 200 to 240 VAC +10 to –15% (50/60 Hz), and the control circuit single-phase 200 to 240 VAC.
Technical reference
| Product name | OMRON R88D-KN02H-ECT OMNUC G5 / Accurax G5 AC servo drive, EtherCAT |
|---|---|
| Brand | OMRON |
| Model | R88D-KN02H-ECT |
| Category | Servo Systems |
| Network | EtherCAT |
| Weight (approx.) | 0.8 kg |
| Control circuit power supply | Single-phase 200-240 VAC |
| Continuous output current (rms) | 1.6 A |
| Max. applicable motor capacity | 200 W |
| Main circuit power supply voltage | Single-phase or 3-phase 200-240 VAC, 50/60 Hz |
| Main circuit power supply capacity | 0.5 kVA |
