OMRON K3MA1102G K3MA-J 24VAC/VDC Digital Process Indicator

Key specifications

Size: 1/8 DIN (96 x 48 mm)
Accuracy: +/- 0.1% full scale
Input type: DC current, DC voltage
Order code: K3MA1102G
Input range: -10 to 10 V, -5 to 5 V, 0 to 20 mA, 0 to 5 V, 1 to 5 V, 4 to 20 mA

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	OMRON K3MA1102G K3MA-J 24VAC/VDC Digital Process Indicator
Brand	OMRON
Model	K3MA1102G
Category	Test & Measurement
Size	1/8 DIN (96 x 48 mm)
Accuracy	+/- 0.1% full scale
Input type	DC current, DC voltage
Order code	K3MA1102G
Input range	-10 to 10 V, -5 to 5 V, 0 to 20 mA, 0 to 5 V, 1 to 5 V, 4 to 20 mA
Output type	None
Number of digits	5
Type designation	K3MA-J 24VAC/VDC
Supply voltage AC/DC	20.4-26.4 V
