OMRON E5CN-HQ2M-500 E5CN-H Digital Temperature Controller
- Brand
- OMRON
- Model
- E5CN-HQ2M-500
- GEARWELL SKU
- GWP-000023034
- Category
- Pressure, Flow & Temperature
Key specifications
- Size
- 1/16 DIN, 48 x 48 x 78 mm
- Evidence
- OMRON datasheet CSM_E5CN-H_DS_E_4_13 (hosted at fa.omron.com.cn)
- Case color
- Black
- Sensor input
- Thermocouple K/J/T/E/L/U/N/R/S/B/W/PL II, Pt100/JPt100, 4-20/0-20 mA, 1-5/0-5/0-10 V
- Control method
- ON/OFF or 2-PID (with auto-tuning)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON E5CN-HQ2M-500 E5CN-H Digital Temperature Controller |
|---|---|
| Brand | OMRON |
| Model | E5CN-HQ2M-500 |
| Category | Pressure, Flow & Temperature |
| Size | 1/16 DIN, 48 x 48 x 78 mm |
| Evidence | OMRON datasheet CSM_E5CN-H_DS_E_4_13 (hosted at fa.omron.com.cn) |
| Case color | Black |
| Sensor input | Thermocouple K/J/T/E/L/U/N/R/S/B/W/PL II, Pt100/JPt100, 4-20/0-20 mA, 1-5/0-5/0-10 V |
| Control method | ON/OFF or 2-PID (with auto-tuning) |
| Control output 1 | Voltage output (for driving SSR), 12 VDC, 21 mA |
| Auxiliary outputs | 2 |
| Code as collected | Omron 欧姆龙 E5CN-HQ2M-500 AC100-240 通用数字温控器 |
| Power supply voltage | 100 to 240 VAC, 50/60 Hz |
