National Instruments PXI-8461 High-Speed CAN Interface Module
- Brand
- National Instruments
- Model
- PXI-8461
- GEARWELL SKU
- GWP-000026409
- Category
- Industrial Communication
Key specifications
- Ports
- 1 or 2
- Evidence
- National Instruments 370289T-01 NI-CAN Hardware and Software Manual (hosted at apexwaves.com)
- Connector
- 9-pin male D-SUB per port
- Isolation
- 60 VDC continuous, channel-to-bus
- Transceiver
- Philips TJA1041
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | National Instruments PXI-8461 High-Speed CAN Interface Module |
|---|---|
| Brand | National Instruments |
| Model | PXI-8461 |
| Category | Industrial Communication |
| Ports | 1 or 2 |
| Evidence | National Instruments 370289T-01 NI-CAN Hardware and Software Manual (hosted at apexwaves.com) |
| Connector | 9-pin male D-SUB per port |
| Isolation | 60 VDC continuous, channel-to-bus |
| Transceiver | Philips TJA1041 |
| Max baud rate | 1 Mbps |
| Power requirement | +5 VDC: 800 mA (1 port), 850 mA (2 ports) typical |
| CAN physical layer | High-speed, ISO 11898 |
