MOXA UC-7420-LX UC-7410/7420 RISC Embedded Computer
- Brand
- MOXA
- Model
- UC-7420-LX
- GEARWELL SKU
- GWP-000023381
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- Intel XScale IXP422 266 MHz (UC-7410/7420)
- LAN
- 2 x 10/100 Mbps RJ45
- Memory
- 128 MB DRAM, 32 MB flash
- Expansion
- USB 2.0 host x 2, PCMCIA, CompactFlash
- Serial ports
- 8 x RS-232/422/485 (RJ45)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MOXA UC-7420-LX UC-7410/7420 RISC Embedded Computer |
|---|---|
| Brand | MOXA |
| Model | UC-7420-LX |
| Category | HMIs & Industrial PCs |
| CPU | Intel XScale IXP422 266 MHz (UC-7410/7420) |
| LAN | 2 x 10/100 Mbps RJ45 |
| Memory | 128 MB DRAM, 32 MB flash |
| Expansion | USB 2.0 host x 2, PCMCIA, CompactFlash |
| Serial ports | 8 x RS-232/422/485 (RJ45) |
| Input voltage | 12 to 48 VDC |
| Code suffix "-LX" | as collected (Linux version); not listed in the current official model table, which lists UC-7420-LX Plus and UC-7420-CE |
| Operating temperature | -10 to 60 °C |
