MOXA ioLogik R1212 R1200 Series 8DI/8DIO RS-485 Remote I/O
- Brand
- MOXA
- Model
- R1212
- GEARWELL SKU
- GWP-000023377
- Category
- PLCs & I/O
Key specifications
- Isolation
- 3k VDC or 2k Vrms
- Input voltage
- 12 to 48 VDC
- Digital output
- Sink, 200 mA per channel
- Serial interface
- 2 x RS-485-2w, Modbus RTU slave
- Counter frequency
- 2.5 kHz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MOXA ioLogik R1212 R1200 Series 8DI/8DIO RS-485 Remote I/O |
|---|---|
| Brand | MOXA |
| Model | R1212 |
| Category | PLCs & I/O |
| Isolation | 3k VDC or 2k Vrms |
| Input voltage | 12 to 48 VDC |
| Digital output | Sink, 200 mA per channel |
| Serial interface | 2 x RS-485-2w, Modbus RTU slave |
| Counter frequency | 2.5 kHz |
| Power consumption | 187 mA @ 24 VDC |
| Operating temperature | -10 to 75 °C |
| Digital input channels | 8 |
| Configurable DIO channels | 8 |
