Moog QAIO 16/4-A MSC Analog I/O Extension Module 16 AI 4 AO
- Brand
- Moog
- Model
- QAIO 16/4-A
- GEARWELL SKU
- GWP-000026661
- Category
- PLCs & I/O
Key specifications
- Connection
- E-Bus (5 MHz) to MSC I / MSC II
- Designation
- QAIO 16/4-A
- Seller code
- 16/4-A
- Analog inputs
- 16 x ±20 mA, 12 bit (multiplex)
- Analog outputs
- 4 x ±10 V, 12 bit, max 5 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Moog QAIO 16/4-A MSC Analog I/O Extension Module 16 AI 4 AO |
|---|---|
| Brand | Moog |
| Model | QAIO 16/4-A |
| Category | PLCs & I/O |
| Connection | E-Bus (5 MHz) to MSC I / MSC II |
| Designation | QAIO 16/4-A |
| Seller code | 16/4-A |
| Analog inputs | 16 x ±20 mA, 12 bit (multiplex) |
| Analog outputs | 4 x ±10 V, 12 bit, max 5 mA |
| Supply voltage | 24 VDC (18 to 36 V) |
| Ordering number | D137-001-006 |
| Reference output | +10 VDC |
| Degree of protection | IP20 |
| Dimensions (W x D x H) | 124 x 170 x 85.5 mm |
