Mitsubishi Electric NZ2EX2B-60DA4 Extension analog output module (D/A)
- Brand
- Mitsubishi Electric
- Model
- NZ2EX2B-60DA4
- GEARWELL SKU
- GWP-000012595
- Category
- PLCs & I/O
Key specifications
- Weight
- 0.23 kg
- Current output
- 0 to 20 mA DC
- Voltage output
- -10 to 10 V DC
- Conversion speed
- 100 µs/channel
- Analog output points
- 4 (4 channels)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Mitsubishi Electric NZ2EX2B-60DA4 is a CC-Link IE Field Network extension digital-analog converter module that connects to the NZ2GF2BN-60DA4 main module to add analog outputs. It has 4 output channels for -10 to 10VDC voltage or 0 to 20mADC current, with digital values of -16000 to 16000 or 0 to 12000. Conversion speed is 100µs per channel and outputs are short circuit protected. It takes 95mA of module power from the main module plus a 24VDC external supply at 135mA, wires to an 18-point two-piece terminal block and weighs 0.23kg.
Technical reference
| Product name | Mitsubishi Electric NZ2EX2B-60DA4 Extension analog output module (D/A) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | NZ2EX2B-60DA4 |
| Category | PLCs & I/O |
| Weight | 0.23 kg |
| Current output | 0 to 20 mA DC |
| Voltage output | -10 to 10 V DC |
| Conversion speed | 100 µs/channel |
| Analog output points | 4 (4 channels) |
| External power supply | 24 VDC (20.4 to 28.8 VDC), 135 mA |
| Module power supply current (from main module) | 95 mA |
