Mitsubishi Electric NZ2GN12A2-16T CC-Link IE TSN remote I/O CC-Link IE TSN remote output module
- Brand
- Mitsubishi Electric
- Model
- NZ2GN12A2-16T
- GEARWELL SKU
- GWP-000030624
- Category
- PLCs & I/O
Key specifications
- Wiring
- M12 connector
- Protection
- IP67
- Power supply
- 24 V DC
- Digital outputs
- 16 (transistor, sink)
- Rated load voltage
- 12-24 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric NZ2GN12A2-16T CC-Link IE TSN remote I/O CC-Link IE TSN remote output module |
|---|---|
| Brand | Mitsubishi Electric |
| Model | NZ2GN12A2-16T |
| Category | PLCs & I/O |
| Wiring | M12 connector |
| Protection | IP67 |
| Power supply | 24 V DC |
| Digital outputs | 16 (transistor, sink) |
| Rated load voltage | 12-24 V DC |
| Dimensions (W x H x D) | 63 x 238 x 37.5 mm |
