Mitsubishi Electric HG-SR202BJ MR-J4 / HG-SR series (2000 r/min, medium inertia, medium capacity) AC servo motor with electromagnetic brake and oil seal
- Brand
- Mitsubishi Electric
- Model
- HG-SR202BJ
- GEARWELL SKU
- GWP-000030612
- Category
- Servo Systems
Key specifications
- Rated speed
- 2000 r/min
- Rated output
- 2.0 kW
- Rated torque
- 9.5 N·m
- Maximum speed
- 3000 r/min
- Rated current
- 9.6 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric HG-SR202BJ MR-J4 / HG-SR series (2000 r/min, medium inertia, medium capacity) AC servo motor with electromagnetic brake and oil seal |
|---|---|
| Brand | Mitsubishi Electric |
| Model | HG-SR202BJ |
| Category | Servo Systems |
| Rated speed | 2000 r/min |
| Rated output | 2.0 kW |
| Rated torque | 9.5 N·m |
| Maximum speed | 3000 r/min |
| Rated current | 9.6 A |
| Maximum torque | 28.6 N·m |
| Power supply capacity | 3.5 kVA |
| Speed/position detector | Absolute/incremental 22-bit encoder (resolution: 4194304 pulses/rev) |
