Mitsubishi Electric FR-F842-07700-2-60 FR-F800 Inverter, separated converter type (fan and pump)
- Brand
- Mitsubishi Electric
- Model
- FR-F842-07700-2-60
- GEARWELL SKU
- GWP-000030484
- Category
- Variable Frequency Drives
Key specifications
- Structure
- Separated converter type (requires FR-CC2 converter unit)
- Voltage class
- 400 V class (380 to 500 V)
- Rated current (LD)
- 683 A
- Type (monitor output)
- CA (terminal CA equipped model)
- Rated inverter current (SLD)
- 770 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric FR-F842-07700-2-60 FR-F800 Inverter, separated converter type (fan and pump) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FR-F842-07700-2-60 |
| Category | Variable Frequency Drives |
| Structure | Separated converter type (requires FR-CC2 converter unit) |
| Voltage class | 400 V class (380 to 500 V) |
| Rated current (LD) | 683 A |
| Type (monitor output) | CA (terminal CA equipped model) |
| Rated inverter current (SLD) | 770 A |
| Applicable motor capacity (LD) | 355 kW |
| Circuit board coating / plated conductor | With coating (IEC 60721-3-3 3C2/3S2) / without plated conductor |
