NIDEC C300-02400018A10100 Commander C300 AC Drive
- Brand
- NIDEC
- Model
- C300-02400018A10100
- GEARWELL SKU
- GWP-000039156
- Category
- Variable Frequency Drives
Key specifications
- Series
- Commander C300 general purpose AC drive
- On-board PLC
- 30 kB user program space
- Motor control
- Open loop vector or V/Hz; open loop RFC-A for induction motors
- Functional safety
- Dual Safe Torque Off, SIL3/PLe, EN/IEC 61800-5-2
- Code suffix "A10100"
- as collected; not listed in the official model-number table
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | NIDEC C300-02400018A10100 Commander C300 AC Drive |
|---|---|
| Brand | NIDEC |
| Model | C300-02400018A10100 |
| Category | Variable Frequency Drives |
| Series | Commander C300 general purpose AC drive |
| On-board PLC | 30 kB user program space |
| Motor control | Open loop vector or V/Hz; open loop RFC-A for induction motors |
| Functional safety | Dual Safe Torque Off, SIL3/PLe, EN/IEC 61800-5-2 |
| Code suffix "A10100" | as collected; not listed in the official model-number table |
| Maker identification | per distributor listings (rs-online.com C300-02400018: 0.55 kW, 3-phase 380-480 V, 1.8 A; axiscontrols.co.uk) |
| Drive overload (default) | 180% for 3 s, 150% for 60 s |
