Mitsubishi Electric FR-F840-55K-1-60 FR-F800 Inverter (fan and pump, energy-saving)
- Brand
- Mitsubishi Electric
- Model
- FR-F840-55K-1-60
- GEARWELL SKU
- GWP-000030482
- Category
- Variable Frequency Drives
Key specifications
- Approx. mass
- 41 kg
- Type (monitor output)
- FM (terminal FM equipped model)
- Rated output current (LD)
- 106 A
- Rated output current (SLD)
- 116 A
- Applicable motor capacity (LD)
- 55 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric FR-F840-55K-1-60 FR-F800 Inverter (fan and pump, energy-saving) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FR-F840-55K-1-60 |
| Category | Variable Frequency Drives |
| Approx. mass | 41 kg |
| Type (monitor output) | FM (terminal FM equipped model) |
| Rated output current (LD) | 106 A |
| Rated output current (SLD) | 116 A |
| Applicable motor capacity (LD) | 55 kW |
| Applicable motor capacity (SLD) | 55 kW |
| Rated input AC voltage/frequency | Three-phase 380 to 500 V, 50/60 Hz |
| Circuit board coating / plated conductor | With coating (IEC 60721-3-3 3C2/3S2) / without plated conductor |
