LENZE E84AVTCE3024SXS 8400 TopLine C 3 kW Frequency Inverter
- Brand
- LENZE
- Model
- E84AVTCE3024SXS
- GEARWELL SKU
- GWP-000015656
- Category
- Variable Frequency Drives
Key specifications
- Mass
- 2.3 kg
- Design
- E = installation (panel mounting)
- Safety engineering
- X = without safety engineering
- Mains voltage range
- 3/PE AC 320 ... 550 V, 45 ... 65 Hz
- Product key: version
- TC = TopLine C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | LENZE E84AVTCE3024SXS 8400 TopLine C 3 kW Frequency Inverter |
|---|---|
| Brand | LENZE |
| Model | E84AVTCE3024SXS |
| Category | Variable Frequency Drives |
| Mass | 2.3 kg |
| Design | E = installation (panel mounting) |
| Safety engineering | X = without safety engineering |
| Mains voltage range | 3/PE AC 320 ... 550 V, 45 ... 65 Hz |
| Product key: version | TC = TopLine C |
| Dimensions (H x W x D) | 270 x 70 x 214 mm |
| Max. output current (60 s) | 11.0 A |
| Typical motor power (rated / increased) | 3.0 / 4.0 kW |
| Rated output current (rated / increased) | 7.3 / 8.8 A |
