KINCO MT100E-4G MT Series 10.1-inch HMI Touch Panel
- Brand
- KINCO
- Model
- MT100E-4G
- GEARWELL SKU
- GWP-000023808
- Category
- HMIs & Industrial PCs
Key specifications
- 4G
- LTE-FDD B1/3/5/8, LTE-TDD B34/38/39/40/41, UMTS B1/8, GSM B3/8
- CPU
- ARM RISC 32-bit 792 MHz
- Memory
- 64 MB RAM / 128 MB flash
- Display
- 10.1" TFT, 1024 x 600, 256K colours
- Ethernet
- 1 port
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KINCO MT100E-4G MT Series 10.1-inch HMI Touch Panel |
|---|---|
| Brand | KINCO |
| Model | MT100E-4G |
| Category | HMIs & Industrial PCs |
| 4G | LTE-FDD B1/3/5/8, LTE-TDD B34/38/39/40/41, UMTS B1/8, GSM B3/8 |
| CPU | ARM RISC 32-bit 792 MHz |
| Memory | 64 MB RAM / 128 MB flash |
| Display | 10.1" TFT, 1024 x 600, 256K colours |
| Ethernet | 1 port |
| Brightness | 350 cd/m2 |
| Input power | DC 10.8-28 V, 7 W at 24 V DC |
| Touch panel | 4-wire resistive |
| Serial ports | COM0 RS232/RS485/RS422; COM1 RS485; COM2 RS232 |
